802.11AX | 1800Mbps | Wi-Fi 6 | 2*Giga

Model: WIS-EAP520-WALL

802.11AX | 1800Mbps | Wi-Fi 6 | 2*Giga
802.11AX | 1800Mbps | Wi-Fi 6 | 2*Giga

MODEL WIS-EAP520-WALL
Standard 802.11ax/ac/b/g/n
Flash SPI NOR 16MB
Memory 128MB
2.4G Frequency 2.4GHz - 2.484GHz
2.4G Wi-Fi standard 802.11b/g/n/ac/ax
5.8G Frequency 5150~5850MHz
5.8G Wi-Fi Standard 802.11 a/n/ac/ax
Interface 2 * 10/100 /1000 RJ45 WAN/LAN Port
  1 * Reset button, press 10 seconds to revert to default setting
  1 * USB Type-C Port
Antenna 2.4G: 2dBi; 5G:4dBi
Data Rate 1800Mbps
End Users 120
RF Power 2.4G≤20dBm; 5.8G≤19dBm
PoE 48V (IEEE 802.3af)
LED light Sys
Power Consumption ≤ 14W
ESD ±6KV
Size 86mmX86mmX35mm
Antenna Speicification
Frequency Range 2.4-2.5GHz
Impedance 50 Ohms nominal
Gain 2dBi
Radiation Omni
Polarization Linear
Firmware Specification
Working Mode Gateway, AP
Wireless Functions Multiple SSID functions: 2.4GHz: 4; 5.8GHz: 4.
  Support SSID hidden
  Support seamless roaming, 802.11kvr standard.
  Support 5G Prior for a faster Ethernet.
  Wireless Security: Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP
  Support MAC filter
  Support Wi-Fi time on/off to save energy
  Support client isolation to improve the wireless stability
  Support RF power adjustable, adjust the RF power based on environment.
  Support user quantity limited, Max 64 users to access each band.
Networking Function VLAN settings
  Cloud access support in gateway mode
Device Management Back-up the configuration
  Restore the configuration
  Reset to factory default
  Reboot the device: including time reboot or reboot immediately
  Admin management password modify
  Firmware upgrade
  System log
  Support firmware GUI web management, AC controller management,
  remote management and cloud management
Protocols IPv4
Package Contents  1800Mbps Dual Band Wall access point
  Mounting Metarial
  Quick Installistation Guide
