2.4Ghz | 300Mbps | 11dBi

Model: WIS-CPE300

2.4Ghz | 300Mbps | 11dBi
2.4Ghz | 300Mbps | 11dBi

Model WIS-CPE300
Flash 8M
DDR2 64M
2.4G frequency 2.412 GHz ~ 2.484GHz
2.4G WIFI protocol 802.11 b / g / n
Antenna 2.4G directional panel antenna, gain：8dBi
Max Rate 300Mbps
2.4G TX Power 802.11b 11M 19±2dBm 1M 20±2dBm
802.11g 54M 17±2dBm 6M 19±2dBm
802.11n HT20 MCS7 16±2dBm MCS0 18±2dBm
802.11n HT40 MCS7 16±2dBm MCS0 18±2dBm
2.4G Receiving Sensitivity 802.11b 11M -85dBm 1M -94dBm
802.11g 54M -73dBm 6M -90dBm
802.11n HT20 MCS7 -71dBm MCS0 -89dBm
802.11n HT40 MCS7 -68dBm MCS0 -86dBm
2.4G EVM 802.11b: ≤-10 dB ；802.11g: ≤-25 dB ；802.11n: ≤-28dB
ppm ±20ppm
WAN 1*10/100M WAN, support 24V passive POE
LAN 1*10/100M LAN
Power PoE 24V, DC 12V
Max Power Consumption <3W
Reset Long press for 10 seconds to restore the factory default configuration, and short press for 1 second to initiate pairing
Switch button Choose AP/ Repeater working mode
Indicators SYS, WAN, LAN, 5G WIFI, signal*4
Dimension 168mm*86mm*39mm
Weight 0.5kg
Temperature Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
IP Grade IP65
ESD Air:±8K, Touch:±6K
Electrical Surge Common Mode: 2K, Differential Mode: 1K
Certification CE, RoHS
