30AP | 60*User | 5*Gigabit WAN/LAN
Model: WHG-30
| MODEL | WHG-30 |
| Protocol | IEEE 802.3, 802.3u, 802.3ab |
| TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS, | |
| IPsec, PPTP, L2TP, CAPWAP Protocol | |
| CPU | MT7621 |
| DDR | 256M |
| Flash | 16M |
| Heat Dissipate | Natural heat dissipation |
| Ports | 4 × 10/100/1000Mbps LAN ports (can set to WAN port) |
| 1 × 10/100/1000Mbps WAN port | |
| Power | DC 12V/0.5A |
| Dimension | 293 *180 *44mm |
| Working | Temperature -20°C~55°C |
| Storage | Temperature -40°C ~ 70°C |
| Working Humidity | 5% ~ 97%RH (No condensation) |
| Firmware features | |
| AP Management | Max to access and manage 60 users |
| Max to manage 30PCS wireless AP | |
| Centrally and remotely to manage/configure wireless AP | |
| View user’s status | |
| Smart Flow Control | One click smart flow control |
| Powerful multiline shunting | |
| Application Priority Automatically | |
| Load Balance | Multiple WAN, multiple ISP network access |
| Intelligence load balance | |
| Ethernet line backup | |
| Ethernet Superimposed | |
| Policy routing: based on IP address, destination IP address, | |
| source MAC address, network port, domain, destination port, | |
| Extranet port, Identity binding | |
| Protocol binding | |
| Routing | Static Routing |
| Behavior Management | All-round to block P2P firmware |
| P2P flow control and bandwidth allot | |
| File and URL filter | |
| Monitor network behavior at all times | |
| Bandwidth limitation | IP-based bandwidth limitation |
| Safeguard / Restrict bandwidth | |
| Time strategy | |
| IP based session restriction | |
| VPN | L2TP, PPTP, VTUNS |
| Security Center | MAC address filter |
| UPR/key words filter | |
| Web content filter | |
| IP address filter | |
| Port mapping | |
| DMZ | |
| Defense Center | TCP/UDP/ICMP flood defense |
| Block TCP scanning | |
| Block ping WAN port | |
| ARP Detection | Send GARP packets |
| ARP Scanning on WAN/LAN port | |
| Online detection | |
| IP-MAC binding | |
| Authentication | PPPoE authentication |
| Portal authentication like Wechat Authentication, WEB | |
| password authentication, SMS authentication IP and MAC | |
| authentication: Allow/deny user access by IP/MAC address | |
| Management | Web/CLI/Telnet management |
| Remote management | |
| DDNS, VPN management | |
| Package Contents | WHG-30*1 |
| Power Cable*1 | |
| Quick Installation Guide | |
| Mounting Material |
WHG-30
