500AP | 500*User | 6*Gigabit WAN/LAN
Model: WHG-500
| MODEL | WHG-500 |
| Storage type | hard disk, SSD, CF Card, DOM |
| Hard disk | 1 x SATAIII 2.5 inch hard disk, capacity optional |
| SSD | 1 x M-SATA SSD, default: 8GB |
| CF card | 1 x TYPEII CF card |
| DOM | 1 x SATA DOM (share hard disk interface) |
| Extend Port | |
| PCIe | No |
| Mini-PCIe | No |
| other | |
| Platfrom | |
| Size | 1U Frame |
| CPU | Intel® Baytrail J1800 2.4GHz/1MB |
| CPU type | Board sticking |
| Chipset | SOC |
| BIOS | SPI AMI EFI BIOS |
| Flash Info | |
| Flash | DDR3 1333/1600 |
| Flash size | Default: 2GB, Optional: 4~8GB |
| Network Interface | |
| Interface | 6 x GbE RJ45 Ports |
| Chipset | 6 x Intel®I211AT |
| BYPASS | 1 group is optional |
| Bypass Control | MCU or GPIO control |
| Serial Port | |
| Port | 1 x RJ45 Serial port |
| Default baud rate | 115200bps |
| Serial port definition | Compatible with Cisco definition |
| I/O Interface | |
| Reset Button | 1PC, to control GPIO or BYPASS |
| Watchdog | Support |
| GPIO | 6 lines |
| Heat Dissipate | No Fan module on mother board |
| 1 x System Fan | |
| Power Supply | |
| Power supply | Build in Open type power supply |
| Power Consumption | 75W |
| Power input | AC 90V-264V @47-63Hz |
| Size, Environment and Certification | |
| Size | 430 (L)×300(W)×44(H)mm |
| Package Size | 545(L)*415(W)*180(H)mm |
| N.W | KG |
| G.W | KG |
| Working Temperature | 0℃-50℃ |
| Storage Temperature | -40℃～70℃ |
| Storage Humidity | 5～95% RH, Non condensing |
| Certification | 3C, ROHS |
| Firmware Spec: | |
| AP Management | Max to access and manage500 users |
| Max to manage 500 PCS wireless AP | |
| Centrally and remotely to manage/configure wireless AP | |
| Smart Flow Control | One click smart flow control |
| Powerful multiline diversion | |
| Application Priority Automatically | |
| Load Balance | Multiple WAN, multiple ISP network access |
| Intelligence load balance | |
| Ethernet line backup | |
| Ethernet Superimposed | |
| Policy routing: based on IP address, destination IP address, | |
| source MAC address, network port, domain, destination port, | |
| Extranet port, Identity binding | |
| Protocol binding | |
| Routing | Static Routing |
| Behavior Management | |
| P2P flow control and bandwidth allot | |
| File and URL filter | |
| Monitor network behavior at all times | |
| Bandwidth limitation | IP-based bandwidth limitation |
| Safeguard / Restrict bandwidth | |
| Time strategy | |
| IP based session restriction | |
| VPN | L2TP, PPTP, VTUNS |
| Security Center | MAC address filter |
| UPR/key words filter | |
| Web content filter | |
| IP address filter | |
| Port mapping | |
| DMZ | |
| Defense Center | TCP/UDP/ICMP flood defense |
| Block TCP scanning | |
| Block ping WAN port | |
| ARP Detection | Send GARP packets |
| ARP Scanning on WAN/LAN port | |
| Online detection | |
| IP-MAC binding | |
| Authentication | PPPoE authentication |
| Portal authentication like Wechat Authentication, WEB password | |
| authentication, One-time password authentication, SMS authentication | |
| Radius authentication: work with the 3rd party radius server | |
| Management | Web/CLI/Telnet management |
| Remote management | |
| Others | DDNS, VPN management |
| Packge Content | WHG-500*1 |
| Power Cable *1 | |
| Installation Accessory | |
| QIG*1 |
WHG-500
