500Mbps+ | Gigabit | 30KM | 2X2 MIMO
Model: WIS-S900AC
| Model | WIS-S900AC | ||||
| CPU | QCA9563+QCA9886+QCA8334 | ||||
| Flash | SPI NOR 16MB | ||||
| DDR | DDR2-128MB | ||||
| 5G Frequency | 5.150GHz～5.850GHz | ||||
| 5G Protocol | 802.11 a / n /ac wave2 | ||||
| Data Rate | 900Mbps | ||||
| Antenna | 2*SMA antenna connectors | ||||
| 5G TX Power | 802.11a | 54M | 21±2dBm | 6M | 24±2dBm |
| 802.11n HT20 | MCS7 | 20±2dBm | MCS0 | 23±2dBm | |
| 802.11n HT40 | MCS7 | 19±2dBm | MCS0 | 22±2dBm | |
| 802.11AC | MCS9 | 18±2dBm | MCS0 | 21±2dBm | |
| 5G Receiving Sensitivity | 802.11a | 54M | -72dBm | 6M | -92dBm |
| 802.11n HT20 | MCS7 | -70dBm | MCS0 | -89dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -87dBm | |
| 802.11AC | MCS9 | -58dBm | MCS0 | -85dBm | |
| 5G EVM | 802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB | ||||
| ppm | ±20ppm,80.000PPS | ||||
| WAN | 1个10/100/1000M WAN, support 24-48V POE power supply | ||||
| LAN | 1个10/100/1000M LAN | ||||
| Power supply | PoE 24V~48V，DC 12~48V | ||||
| Power consumption | < 15W | ||||
| RST button | Press the key for 2 to 5 seconds to automatically pair, and press and hold for 10 seconds to restore the factory default configuration | ||||
| Switch button | One key switch between Master and Slave CPE | ||||
| Indicators | SYS, WAN, LAN, 5G WIFI, signal*4 | ||||
| Dimension | 196mm*86mm*40mm | ||||
| Weight | 0.4kg | ||||
| Temperature | Working: -30°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing) | ||||
| IP Grade | IP65 | ||||
| ESD | Air:±8K, Touch:±4K | ||||
| Electrical Surge | Common Mode: 4K, Differential Mode: 2K | ||||
| Software | |||||
| Wireless operating modes | Access point (auto WDS), access point (TDMA3 ), station (WDS, TDMA3 ), station (ARP NAT) | ||||
| Wireless techniques | Smart station polling, smart auto-channel, adaptive auto modulation, automatic transmit power control (ATPC) | ||||
| Wireless security | WPA/WPA2 personal, WPA/WPA2 enterprise, WACL, user isolation | ||||
| Wireless QoS | 4 queues prioritization on TDMA | ||||
| Network operating mode | Bridge, router iPv4, router IPv6 | ||||
| Network techniques | Routing with and without NAT, VLAN | ||||
| WAN protocols | Static IP, DHCP client, PPPoE client | ||||
| Services | DHCP server, SNMP server, NTP client, router advertisement daemon, ping watchdog | ||||
| Management | HTTP(S) GUI, SSH, SNMP read, WNMS, Telnet | ||||
| Tools | Site survey, link test, antenna alignment | ||||
| Warranty | 2 Year | ||||
| Regulatory | |||||
| Certification | CE/ROHS | ||||
WIS-S900AC
