5GHz | 900Mbps | 12dBi
Model: WIS-CPE900
| Model | WIS-CPE900 | ||||
| Flash | 8M | ||||
| DDR2 | 64M | ||||
| 2.4G frequency | 5.150GHz～5.850GHz | ||||
| 2.4G WIFI protocol | 802.11 a / n /ac | ||||
| Antenna | 5.8G directional panel antenna, gain：12dBi | ||||
| Max Rate | 900Mbps | ||||
| 5G TX Power | 802.11a | 54M | 17±2dBm | 6M | 19±2dBm |
| 802.11n HT20 | MCS7 | 16±2dBm | MCS0 | 18±2dBm | |
| 802.11n HT40 | MCS7 | 16±2dBm | MCS0 | 18±2dBm | |
| 802.11ac VHT20 | MCS9 | 16±2dBm | MCS0 | 18±2dBm | |
| 802.11ac VHT40 | MCS9 | 15±2dBm | MCS0 | 17±2dBm | |
| 802.11ac VHT80 | MCS9 | 15±2dBm | MCS0 | 17±2dBm | |
| 5G Receiving Sensitivity | 802.11a | 54M | -75dBm | 6M | -92dBm |
| 802.11n HT20 | MCS7 | -71dBm | MCS0 | -89dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm | |
| 802.11ac VHT20 | MCS9 | -64dBm | MCS0 | -87dBm | |
| 802.11ac VHT40 | MCS9 | -59dBm | MCS0 | -84dBm | |
| 802.11ac VHT80 | MCS9 | -56dBm | MCS0 | -81dBm | |
| 5G EVM | 802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB | ||||
| ppm | ±20ppm | ||||
| WAN | 1*10/100M WAN, support 24V passive POE | ||||
| LAN | 1*10/100M LAN | ||||
| Power | PoE 24V, DC 12V | ||||
| Max Power Consumption | <5W | ||||
| Reset | Long press for 10 seconds to restore the factory default configuration, and short press for 1 second to initiate pairing | ||||
| Switch button | Choose AP/ Repeater working mode | ||||
| Indicators | SYS, WAN, LAN, 5G WIFI, signal*4 | ||||
| Dimension | 168mm*86mm*39mm | ||||
| Weight | 0.5kg | ||||
| Temperature | Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing) | ||||
| IP Grade | IP65 | ||||
| ESD | Air:±8K, Touch:±6K | ||||
| Electrical Surge | Common Mode: 2K, Differential Mode: 1K | ||||
| Certification | CE, RoHS | ||||
QIG OF CPE
