802.11AC | Dual Band | 1200Mbps

Model: WIS-EAP500-WALL

802.11AC | Dual Band | 1200Mbps
802.11AC | Dual Band | 1200Mbps

MODEL WIS-EAP500-WALL
Flash 8M Flash
DDR 64M DDR
Interface 1*10/100Mbps LAN port(Can be used as WAN)
  1*10/100Mbps LAN ports
  1*WiFi Switch On/Off button
  1*Reset button
Power Supply 48V PoE,  IEEE 802.3af  standard
Maxi power consumption <6W
Dimensions (W X D X H) 87*86*35.8mm
Antenna Type On board WiFi antenna
  2.4G: 3dBi omni antenna
  5.8G: 5dBi omni antenna
Wireless Features
Wireless Standards IEEE 802.11ac/n/a 5GHz;
  IEEE 802.11n/g/b 2.4GHz
Frequency 5GHz : 5.150GHz～5.850GHz
  2.4GHz: 2.4GHz – 2.484GHz
Signal Rate 5GHz: Up to 900Mbps;
  2.4GHz: Up to 300Mbps
RF Power (2.4GHz) 802.11b 11M    17±2dBm     1M   19±2dBm
  802.11b  11M    17±2dBm     1M   19±2dBm
  802.11g 54M    16±2dBm     6M   18±2dBm
  802.11nHT20    MCS7                 15±2dBm     MCS0   17±2dBm
RF Power (5GHz) 802.11nHT40  MCS7    14±2dBm     MCS0   16±2dBm
  802.11a 54M   16±2dBm     6M   18±2dBm
  802.11n HT20 MCS7    15±2dBm     MCS0   17±2dBm
  802.11n HT40  MCS7    14±2dBm     MCS0   16±2dBm
Receive Sensitivity (2.4GHz) 802.11n  HT40       MCS7    -68dBm     MCS0
  802.11b        11M             -68dBm 1am    -94dBm
  802.11g        54M            -72dBm 6m    -90dBm
  802.11n HT20   MCS7    -70dBm     MCS0    -88dBm
Receive Sensitivity (5GHz) 802.11n HT40   MCS7    -68dBm     MCS0    -86dBm
  802.11a 54M     -72dBm      6M    -90dBm
  802.11n HT20      MCS7     -70dBm     MCS0     -88dBm
  802.11n HT40     MCS7     -68dBm     MCS0     -86dBm
Wireless 802.11ac HT80    MCS9     -58dBm       MCS0     -82dBm
  Distance Control (802.1x Ack timeout)
  Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G)
  BSSID
EVM 2.4G: 802.11b: ≤-10 dB; 802.11g: ≤-25dB; 802.11n: ≤-28 dB
  5G:  802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB
PPM ±20ppm
Max Access Users 80
Operation Mode Wireless AP, Gateway, Wi-Fi Repeater
Wireless Securit0y OPEN、WPA、WPA2、WPA-PSK、WPA2-PSK
ESD - I Air discharge:±4KV
Surge Common-mode: ±2KV
LED Status SYS
Management
System  Setting Web-based configuration / Software AC controller and Hardware AC
  controller management
Firmware Upgrade Upgrade firmware via web browser or AC controller
Administration Admin Password can be configured
System monitoring Watch dog, Status in hand , useful statistic and Event log
Logs Supports local logs, logs host, logs file export
Reset Reset or factory defaults
Backup Restore settings & configuration of the device to local file, Scheduled reboot
Others
Environment Operating Temperature: -20~55° C
  Extreme Temperature: -40~70° C
  Storage Temperature: -40~70° C
  Humidity: 5%~95% non-condensing
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8,
  Windows 10, MAC OS, NetWare, UNIX or Linux
Package Contents 1200Mbps Dual Band wall access point
  Mounting Material
  Quick Installistation Guide
