802.11AC | Dual Band | 1200Mbps | 2*Giga
Model: WIS-EAP510-WALL
| MODEL NO | WIS-EAP510-WALL | ||||
| Chipset | QCA9563 + QCA9886 +QCA8337 | ||||
| Flash | 16M Flash | ||||
| DDR | 128M DDR | ||||
| Interface | 1*10/100/1000Mbps WAN port | ||||
| 1*10/100/1000Mbps LAN ports | |||||
| Power Supply | 48V PoE, IEEE 802.3af standard | ||||
| Maxi power consumption | < 8W | ||||
| Dimensions (W X D X H) | 86*86*35mm | ||||
| Antenna Type | Build in dual band 2dBi antenna | ||||
| WIRELESS FEATURES | |||||
| Wireless Standards | IEEE 802.11ac/n/a 5GHz; | ||||
| IEEE 802.11n/g/b 2.4GHz | |||||
| Frequency | 5GHz : 5.150GHz～5.850GHz | ||||
| 2.4GHz: 2.4GHz – 2.484GHz | |||||
| Signal Rate | 5GHz: Up to 900Mbps; | ||||
| 2.4GHz: Up to 300Mbps | |||||
| RF Power (2.4GHz) | 802.11b | 11M | 17±2dBm | 1M | 19±2dBm |
| 802.11g | 54M | 16±2dBm | 6M | 18±2dBm | |
| 802.11n HT20 | MCS7 | 15±2dBm | MCS0 | 17±2dBm | |
| 802.11n HT40 | MCS7 | 14±2dBm | MCS0 | 16±2dBm | |
| RF Power (5GHz) | 802.11a | 54M | 16±2dBm | 6M | 18±2dBm |
| 802.11n HT20 | MCS7 | 15±2dBm | MCS0 | 17±2dBm | |
| 802.11n HT40 | MCS7 | 14±2dBm | MCS0 | 16±2dBm | |
| 802.11ac HT80 | MCS9 | 13±2dBm | MCS0 | 15±2dBm | |
| Receive Sensitivity (2.4GHz) | 802.11b | 11M | -85dBm | 1M | -94dBm |
| 802.11g | 54M | -72dBm | 6M | -90dBm | |
| 802.11nHT20 MCS7 | -70dBm | MCS0 | -88dBm | ||
| 802.11n HT40 MCS7 | -68dBm | MCS0 | -86dBm | ||
| Receive Sensitivity (5GHz) | 802.11a | 54M | -74dBm | 6M | -90dBm |
| 802.11n HT20 | MCS7 | -72dBm | MCS0 . | -88dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 . | -86dBm | |
| 802.11ac HT80 | MCS9 | -58dBm | MCS0 . | -80dBm | |
| Wireless | Auto-Channel selection | ||||
| Distance Control (802.1x Ack timeout) | |||||
| Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G) | |||||
| BSSID | |||||
| EVM | 2.4G: 802.11b: ≤-10 dB; 802.11g: ≤-25dB; 802.11n: ≤-28 dB | ||||
| 5G: 802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB | |||||
| PPM | ±20ppm | ||||
| Max Access Users | 120 | ||||
| Operation Mode | Wireless AP, Gateway, Wi-Fi Repeater | ||||
| Wireless Security | 64/128-bit WPA / WPA2, WPA-PSK/ WPA2-PSK encryption | ||||
| LED Status | Wi-Fi, LAN, SYS | ||||
| Management | |||||
| System Settings | Web-based configuration (HTTP/Telnet) | ||||
| Firmware Upgrade | Upgrade firmware via web browser or TFTP | ||||
| Administration | Admin Password can be configured | ||||
| System monitoring | Watch dog, Status in hand , useful statistic and Event log | ||||
| Logs | Supports local logs, logs host, logs file export | ||||
| Reset | Reset or factory defaults | ||||
| Backup | Restore settings & configuration of the device to local file, | ||||
| Scheduled reboot | |||||
| Others | |||||
| Environment | Operating Temperature: -20~55° C | ||||
| Extreme Temperature: -40~70° C | |||||
| Storage Temperature: -40~70° C | |||||
| Humidity: 5%~95% non-condensing | |||||
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, | ||||
| Windows 10, MAC OS, NetWare, UNIX or Linux | |||||
| Package Contents | 1200Mbps Dual Band Wall access point | ||||
| Mounting Material | |||||
| Quick Installistation Guide |
WIS-EAP510-WALL
