802.11AC | Dual Band | 1200Mbps | 2*Giga
Model: WIS-EAP510-OUTDOOR
Fast Auto Roaming
Fast roaming allows automatic switching between access points because you are moving
so you are connected to the strongest signal and never lose the connection
| MODEL | WIS-EAP510-OUTDOOR |
| Chipset | Qualcomm QCA9563+QCA9886+QCA8334 |
| Standard | 802.11ac/b/g/n, MIMO technology |
| Memory | 128MB DDR2 RAM |
| Flash | 16MB |
| Interface | 2 * 10/100/1000Mbps RJ45 LAN Port |
| 1 * Reset button, press 15 seconds to revert to default setting | |
| Antenna | Build in omni antenna, 5dBi, MIMO |
| Power consumption | 48V PoE<30W |
| Size | 315mm * 145 mm * 80 mm |
| Frequency | 2.4G: 802.11b/g/n; 5GHz: 802.11a/n/ac |
| 2.4GHz: 2.4GHz to 2.484GHz | |
| 5GHz: 5150 -5850 GHz | |
| Modulation | OFDM = BPSK,QPSK, 16-QAM, 64-QAM |
| DSSS = DBPSK, DQPSK, CCK | |
| Data Rate | 1200Mbps (2.4G 300Mbps, 5.8G 900Mbps) |
| RF Power | 2.4G: ≤27dBm |
| 5G: ≤27dBm | |
| IP Level | IP65 |
| Power consumption | < 20W |
| ESD | Differential Mode: ±2KV |
| Max Users | 120 |
| Product Size | 315mm*145mm*80mm |
| Firmware Features: | |
| Operation mode | Wireless AP, Gateway, WISP, WiFi Repeater |
| WAN Type | Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access) |
| Wireless Security | WPA / WPA2, WPA-PSK/ WPA2-PSK |
| SSID | Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G) |
| Firewall | DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter |
| IP and MAC Address Binding | |
| Protocols | IPv4 |
| Antenna specification | |
| Frequency Range | 2.4GHzGHz |
| Gain | 5dBi |
| V.S.W.R | ≤2 |
| Impendance | 50Ω |
| Polarization | Vertical |
| Radiation | Omni |
| Others: | |
| Environment | Operating Temperature: -30~45 ℃ |
| Maximum Working Temperature: -40 ~55℃( Throughput some attenuation) | |
| Storage Temperature: -40~70 ℃ | |
| Storage Humidity: 5%~95% non-condensing | |
| Management | Firmware GUI , Remote Management, WLAN Controller, Cloud Management System |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, |
| Windows 8, MAC OS, NetWare, UNIX or Linux | |
| Package Contents | 1200Mbps Dual Band Outdoor access point |
| Mounting Material | |
| Quick Installation Guide |
WIS-EAP510-OUTDOOR
