802.11AC | Dual Band | 1200Mbps
Model: WIS-EAP500
Flexible Power Supply Mode
Standard PoE power supply is used, no external power supply is required, and each AP only need one network cable,
whitch is convenient forconstruction and fiexible in use.
Fast Auto Roaming
Fast roaming can realiza the switching time between AP and AP in milliseconds, basically without packet loss, while using video and playing games,
when moving between multiple APs, the mobile phone and tablet will automatically switch to the with the best signal.
| MODEL | WIS-EAP500 |
| Standard | 802.11ac/b/g/n, MIMO technology |
| Memory | 64MB |
| Flash | SPI NOR 8MB |
| Interface | 1 * 10/100Mbps RJ45 LAN Port(Can be used as WAN ) |
| 1 * 10/100Mbps RJ45 LAN Port | |
| 1 * Reset button, press 15 seconds to revert to default setting | |
| Antenna | Build in 5dBi 2.4GHz MIMO Antenna |
| Build in 4dBi 5.8GHz MIMO Antenna | |
| Size | 188*33mm |
| PoE | 48V 0.5A |
| DC | 12V 1A |
| LED Indicator | Sys, 2.4G WIF, 5.8G WIFI, LAN,2*LAN |
| Max Power Consumption | < 10W |
| ESD | ±6KV |
| Surge Protection | Different mode: ±2KV |
| RF Data | |
| Frequency | 2.4G:802.11b/g/n: 2.4GHz~2484GHz |
| 5GHz:802.11a/n/ac: 5150MHz ~5850MHz | |
| Country code | FCC、IC、ETSI、MKK、MKK1、MKK2 |
| MKK3、NCC、RUSSIAN、CN | |
| Modulation | OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM |
| DSSS = DBPSK, DQPSK, CCK | |
| Throughput | 1200Mbps |
| RF Power (2.4GHz) | <22dBm |
| RF Power (5GHz) | <21dBm |
| PPM | ±20ppm |
| Max Users | 80+ |
| Firmware Features: | |
| Operation mode | Wireless AP: Plug and Play. |
| Gateway: Dynamic IP/Static IP/PPPoE | |
| Wireless Functions | Multiple SSID functions: 2.4GHz: 4; 5.8GHz: 4 |
| Support SSID hidden | |
| Support SSID broadcast | |
| Support 5G Prior for a faster Ethernet. | |
| Wireless Security: OPEN, WPA, WPA2, WPA-PSK, WPA2-PSK | |
| Support MAC filter | |
| Support Wi-Fi time on/off to save energy | |
| Support client isolation to improve the wireless stability | |
| Support RF power adjustable, adjust the RF | |
| power based on environment. | |
| Short GI Enable and Disable | |
| Support user quantity limited, Max 128 users to access each band. | |
| Networking Function | VLAN settings |
| Cloud access support in gateway mode | |
| Device Management | Back-up the configuration |
| Restore the configuration | |
| Reset to factory default | |
| Reboot the device: including time reboot or reboot immediately | |
| Admin management password modify | |
| Firmware upgrade | |
| System log | |
| Support firmware GUI web management, AC controller management, | |
| remote management and cloud management | |
| Protocols | IPv4 |
| Antenna specification | |
| Frequency Range | 2.4GHz & 5.8GHz |
| Impedance | 50 Ohms nominal |
| Gain | 4dBi |
| Radiation | Omni |
| Polarization | Vertical |
| S-Parameters (2.4G&5.8G) | |
| Others | |
| Environment | Operating Temperature: -20~55 ℃ |
| Temperature: -40~70 ℃ | |
| Humidity: 5%~95% non-condensing; | |
| Storage Humidity: 5%~90% non-condensing | |
| Management | Firmware GUI , Remote Management, |
| WLAN Controller, Cloud Management System | |
| Package Contents | 1200Mbps Dual Band wireless access point |
| Mounting Material | |
| Quick Installation Guide |
WIS-EAP500
