802.11AX | Wi-Fi 6 | 1800Mbps | 2*Giga
Model: WIS-EAP520-OUTDOOR
Fast Auto Roaming
Fast roaming allows automatic switching between access Pointed because you are moving so you are connected to the
strongest signal and never lose the connection
| MODEL | WIS-EAP520-OUTDOOR |
| Chipset | IPQ6000 |
| Standard | 802.11ax/ac/b/g/n |
| Flash | SPI NOR 8MB (1.8v) + NAND 128MB |
| DDR3L | 512MB |
| 2.4G Frequency | 2.4GHz - 2.484GHz |
| 2.4G Wi-Fi standard | 802.11b/g/n/ax |
| 5.8G Frequency | 5150~5850MHz |
| 5.8G Wi-Fi Standard | 802.11 a/n/ac/ax |
| Interface | 2 * 10/100 /1000 RJ45 LAN Port(Can be used as WAN port) |
| 1 * Reset button, press 10 seconds to revert to default setting | |
| Antenna | Build in omni antenna, 6dBi @ 2.4GHz; 6dBi @ 5.8GHz |
| Data Rate | 1800Mbps |
| End Users | 160+ |
| 2.4G RF Power | ≤ 24dBm |
| 5.8G RF Power | ≤ 24dBm |
| PoE | 48V (IEEE 802.3at) |
| LED light | Sys, WAN |
| Antenna spicification | ≤ 24W |
| Power Consumption | 2.4GHz& 5.8GHz |
| Frequency Range | |
| Impedance | 50 Ohms |
| Gain | 6dBi @ 2.4GHz, 6dBi @ 5.8GHz |
| Polarization | Linear |
| Others: | |
| Environment | Operating Temperature: -20~45°C |
| Limit working temperature: -30~70°C | |
| Storage Temperature: 0~70°C | |
| Humidity: 5%~95% non-condensing | |
| Package Contents | 1800Mbps Dual Band Outdoor access point |
| Mounting Material | |
| Quick Installation Guide |
WIS-EAP520-OUTDOOR
