802.11AX | WIFI 6 | 2* Giga -

Model: WIS-EAP530L-OUTDOOR

802.11AX | WIFI 6 | 2* Giga -
802.11AX | WIFI 6 | 2* Giga -


Strong WiFi Signal and Long-Range Coverage

Dual Band 2.4GHz and 5GHz 802.11ac Wave2 Mu-MIMO technology, with a data rate of up to 3000Mbpps, which can access 150+ users and cover Upto 300  meters,
improving the overall network performance Mulit-client density environment

Fast Auto Roaming

Fast roaming allows automatic seitching between access pointd, because you are moving so you are connected to the strongest signal and never lose the connection



Model                               WIS-EAP530L-OUTDOOR
Chipset                                        Qualcomm
Standard  802.11ax/ac/b/g/n/a
Flash  SPI NOR 8MB SPI NAND 128MB
DDR3L  External 512MB*1
2.4G Frequency           2.4GHz ~ 2.484GHz
2.4G Wi-Fi standard  802.11b/g/n/ac /ax
5.8G Frequency 5.150GHz～5.825GHz
5.8G Wi-Fi Standard  802.11a/n/ ac /ax
Interface                                1 10/100/1000/adaptive WAN port, support POE 48V power supply;
                                                     1 Console port
Antenna  Build in 4*6dBi dual band MIMO Antenna
Data Rate 3000Mbps （2.4G 600Mbps, 5.8G 2400Mbps）
End Users           150+
2.4G RF Power ≤ 23dBm
5.8G RF Power ≤ 23dBm
DC 12V----2A
PoE 48V (IEEE 802.3at)
LED light                    Sys, WAN, LAN
Power Consumption ≤ 20W
Size TBD
Working Mode                          Gateway, AP
wireless function SSID broadcast
  SSID quantity: 4 (2.4GHz) + 4 (5GHz), support Chinese SSID
   Hide SSID function
  Wireless encryption: OPEN , WPA/WPA2PSK-TKIPAES, WPA3PSK-TKIPAES
  Wireless MAC address filtering: support white list
  Spectrum Navigation (5G Priority)
  WiFi timing off function
  User isolation: isolation between wireless networks, internal isolation of AP
   Transmit power setting
   Wireless client limit
   QoS: WMM
Internet function Connection method: Static address, obtained from the management server, obtained from the
                                               gateway
   DHCP server: either a built-in DHCP server or an external DHCP server
  Cloud platform server
  firewall function
  PPPOE function: support PPPOE dial-up function
device management              Backup configuration information
  Restoring configuration information
  reset
  Restart includes scheduled restart and immediate restart
  firmware upgrade
  Time management including system display time and time synchronization
Antenna Specification
Frequency Range 2.4GHz & 5.8GHz
Impedance 50 Ohms nominal
Gain 6dBi
Radiation Omni
Polarization Vertical
