802.11AX | WIFI 6 | 2* Giga.

Model: WIS-EAP530-OUTDOOR

802.11AX | WIFI 6 | 2* Giga.
802.11AX | WIFI 6 | 2* Giga.

Strong WiFi Signal and Long-Range Coverage

Dual Band 2.4GHz and 5GHz 802.11ac Wave2 Mu-MIMO technology, with a data rate of up to 3000Mbpps, which can access 150+ users and
cover Upto 200  meters, improving the overall network performance Mulit-client density environment


Fast Auto Roaming

Fast roaming allows automatic seitching between access pointd, because you are moving so you are connected to
the strongest signal and never lose the connection


Model                                              WIS-EAP530-OUTDOOR
Chipset                                            Qualcomm
Standard  802.11ax/ac/b/g/n/a
Flash SPI NOR 8MB SPI NAND 128MB
DDR3L External 512MB*1
2.4G Frequency          2.4GHz ~ 2.484GHz
2.4G Wi-Fi standard  802.11b/g/n/ac /ax
5.8G Frequency 5.150GHz～5.825GHz
5.8G Wi-Fi Standard  802.11a/n/ ac /ax
Interface                                       1 10/100/1000/adaptive WAN port, support POE 48V power supply;
                                                          1 Console port
Antenna 2* 2.4G antennas, each gain: 6 dBi
                                                          2* 5.8G antennas, each gain: 6 dBi
Data Rate 3000Mbps （2.4G 600Mbps, 5.8G 2400Mbps）
End Users           150
2.4G RF Power ≤ 23dBm
5.8G RF Power ≤ 23dBm
DC 12V----2A
PoE 48V (IEEE 802.3at)
LED light                    Sys, WAN, LAN
ESD       15 kV
Lightning Protection         6 kV
Power Consumption ≤ 20W
Size  TBD
Working Mode                             Gateway & AP mode
Wireless Functions     SSID broadcast
                                                          SSID quantity: 4 (2.4GHz) + 4 (5GHz)
                                                    Hide SSID function
                                                          Wireless encryption: OPEN , WPA/WPA2PSK-TKIPAES, WPA3PSK-TKIPAES
                                                          Wireless MAC address filtering: support white list
                                                           Spectrum Navigation (5G Priority)
                                                            WiFi timing off function
                                                          User isolation: isolation between wireless networks, internal isolation of AP
                                                          Transmit power setting
                                                         Wireless client limit
                                                          QoS: WMM
Networking Function               Connection method: Static address, obtained from the management server,
                                                          obtained from the gateway
                                                          DHCP server: either a built-in DHCP server or an external DHCP server
                                                          Cloud platform server
                                                         firewall function
                                                         PPPOE function: support PPPOE dial-up function
Device Management      Backup configuration information
          Restoring configuration information
                                                           reset
                                                          Restart includes scheduled restart and immediate restart
                                                           firmware upgrade
                                                           Time management including system display time and time synchronization
                                                           system log
                                                          Fat and thin AP switching function

Antenna Specification
Frequency Range 2.4GHz & 5GHz
Impedance 50 Ohms nominal
Gain 6dBi
Radiation Omni
Polarization Vertical
