5GHz | Gigabit | 25dBi | 25Km
Model: WIS-D525ACPro
| Model | WIS-D525ACPro | ||||
| CPU | QCA9563+QCA9882+QCA8334 | ||||
| Flash | SPI NOR 16MB | ||||
| DDR2 | 64MB | ||||
| 5G Band | 5.150GHz～5.850GHz | ||||
| 5G WIFI Protocol | 802.11 a / n /ac | ||||
| Maximum rate | 900Mbps | ||||
| Antenna | Integrated 25dBi dual polarization dish antenna | ||||
| 5G Tx power | 802.11a | 54M | 23± 2dBm | 6M | 26± 2dBm |
| 802.11n | MCS7 | 22± 2dBm | MCS0 | 26± 2dBm | |
| HT20 | |||||
| 802.11n | MCS7 | 22± 2dBm | MCS0 | 26± 2dBm | |
| HT40 | |||||
| 802.11ac | MCS9 | 21± 2dBm | MCS0 | 26± 2dBm | |
| VHT20 | |||||
| 5G Receiving | 802.11ac | MCS9 | 21± 2dBm | MCS0 | 26± 2dBm |
| sensitivity | VHT40 | ||||
| 802.11ac | MCS9 | 21± 2dBm | MCS0 | 26± 2dBm | |
| VHT80 | |||||
| 802.11a | 54M | -75dBm | 6M | -92dBm | |
| 802.11n | MCS7 | -72dBm | MCS0 | -90dBm | |
| HT20 | |||||
| 5G EVM | 802.11a_54M: ≤ -25 dB；802.11n_MCS7: ≤ -28 dB；802.11AC_MCS9:≤ -32dB | ||||
| frequency deviation（ppm） | ±20ppm | ||||
| Port (WAN) | 1*10/100/1000M WAN, support 48V POE | ||||
| Port（LAN） | 1*10/100/1000M LAN | ||||
| Supply | 802.3af，DC 12~24V | ||||
| Consumption | <10 W | ||||
| Reset Button | Long press for 6-10 seconds to restore factory default configuration | ||||
| LED | SYS, WAN, LAN, 5G WIFI, signal*4 | ||||
| Size | Φ466mm*260mm | ||||
| Weight | 2.9KG | ||||
| Environment | Operating temperature: -40°C to 70°C | ||||
| Storage temperature: -40°C to 70°C；humidity：5％～95％（No condensation） | |||||
| IP grade | IP66 | ||||
| ESD | Air +/-15K，Contact +/-6K | ||||
| Lightning Protection | 4kV | ||||
WIS-D525ACPro
